DATAKOM D-100 MK2

Description

DATAKOM D-100 MK2 is a versatile and advanced genset controller designed for efficient and reliable generator set management.

Features:

Multifunctional Control:

Modes of Operation:

• Automatic Mains Failure (AMF) with uninterrupted transfer.
• Automatic Transfer Switch (ATS) with uninterrupted transfer.
• Remote start and manual start capabilities.
• Standalone engine controller functionality.

Communication Interfaces:

Integrated Communication Options:

• GSM Modem (2G/3G/4G).
• Ethernet 10/100 Mbps.
• Wi-Fi support.
• RS-485 and RS-232 isolated serial communication.
• USB Device for local programming.
• J1939 CANBUS for engine communication.

Remote Monitoring:

• Access via the internet, SMS alerts, or dedicated software like Rainbow Plus and Rainbow Scada.

Flexible Topologies:

• 3-phase 4-wire (star), 3-phase 3-wire (delta), 1-phase, and other custom setups.
• CTs can be installed on either the genset or load side.

Advanced Monitoring and Protection:

• Real-time monitoring of voltage, current, power, and frequency.
• Overload protection with IDMT characteristics.
• Load shedding and dummy load management for efficient energy use.
• Automatic fuel pump and pre-heating controls.
• Comprehensive alarms for over/under-voltage, frequency, and engine conditions.

Data Logging:

• Stores up to 400 event logs with detailed snapshots.
• Historical data helps in performance analysis and troubleshooting.

User Interface:

• A graphic LCD display with intuitive navigation.
• Pushbuttons for local control and configuration.
• Status indicators for mains, generator, and alarms.

Technical Specifications:

Power Supply:

• Operating Voltage: 8 to 36 VDC.
• Handles cranking dropouts and overvoltage.

AC Voltage Input:

• True RMS measurement.
• Voltage Range: 14 to 300 VAC.

AC Current Input:

• True RMS compatible with 5A CTs.
• Configurable CT ratios for different setups.

Digital and Analog Inputs/Outputs:

• Configurable for various engine and generator parameters, such as:
• Oil pressure, coolant temperature, fuel level, etc.
• Protected digital outputs for controlling cranking, fuel solenoids, alarms, etc.

Environmental Standards:

• Designed to meet stringent industrial standards for vibration, electromagnetic compatibility (EMC), and environmental conditions.

Applications:

• Industrial and commercial generator installations.
• Backup power systems with automatic transfer capabilities.
• Remote monitoring and control applications via internet or GSM.
