DATAKOM SBC-125 Battery Charger

DATAKOM SBC-125 is (Original) and made in Turkey. It is an advanced Smart Battery Charger designed for reliable charging and maintenance of 12V batteries in various applications. It ensures optimal battery performance and extended battery life with intelligent charging algorithms and robust safety features. The SBC-125 is ideal for industrial, commercial, and residential uses, such as backup generators, solar systems, and DC power systems.

(Note: Bulk quantity pricing often differs from unit prices.)



Add to quote
Category: Tags: , , , , , , , ,

Description

DATAKOM SBC-125 is an advanced Smart Battery Charger designed for reliable charging and maintenance of 12V batteries in various applications. It ensures optimal battery performance and extended battery life with intelligent charging algorithms and robust safety features. The SBC-125 is ideal for industrial, commercial, and residential uses, such as backup generators, solar systems, and DC power systems.

Features:

Intelligent Charging:

  • Supports multi-stage charging for better battery performance.
  • Automatic adjustment of charging parameters based on the battery state.

Wide Compatibility:

  • Designed for 12V lead-acid batteries, including flooded, AGM, and gel types.

High Output Current:

  • Provides up to 25A of charging current, suitable for large-capacity batteries.

Voltage and Current Regulation:

  • Maintains a steady and controlled output for safe and efficient charging.

Battery Maintenance Mode:

  • Keeps the battery fully charged without risk of overcharging during standby periods.

Advanced Protections:

  • Equipped with protections for overload, reverse polarity, short circuit, and overheating.

LED Status Indicators:

  • Real-time LED indicators for charging status and fault conditions.

Robust Design:

  • Compact, durable, and built for long-term use in industrial environments.

Specifications:

Electrical:

Input Voltage:

  • 180–260 VAC (50/60 Hz).

Output Voltage:

  • Nominal: 12V DC.
  • Float Charge Voltage: 13.6V–13.8V DC.
  • Boost Charge Voltage: 14.2V–14.5V DC.

Output Current:

  • Maximum: 25A (regulated).

Efficiency:

  • High efficiency for energy-saving operation.

Environmental:

  • Operating Temperature: -20°C to +55°C.
  • Storage Temperature: -30°C to +70°C.
  • Humidity: Up to 95% non-condensing.

Mechanical:

  • Compact and easy to mount in various applications.
  • Weight: Lightweight for ease of handling.

Applications:

Standby Power Systems:

  • Ideal for charging and maintaining generator starter batteries.

Solar and Renewable Energy:

  • Used in off-grid solar setups and backup energy systems.

Industrial Use:

  • Suitable for large battery banks in industrial control systems.

Automotive and Marine:

  • Charging batteries in vehicles, boats, and RVs.

Charging Algorithm:

The SBC-125 uses a 3-stage charging process:

Bulk Charge:

  • Delivers maximum current to rapidly charge the battery.

Absorption Charge:

  • Holds the voltage constant while reducing the current, ensuring the battery reaches full capacity.

Float Charge:

  • Maintains the battery at full charge with minimal current to prevent overcharging.

Installation:

Connections:

  • Connect the positive (+) and negative (-) terminals to the battery.
  • Plug the charger into a 230V AC power outlet.

Mounting:

  • Wall-mount or place on a stable surface.
  • Ensure good ventilation around the charger for heat dissipation.

Configuration:

  • The charger automatically detects the battery type and adjusts settings accordingly.
  • For specific requirements, refer to the manual for advanced configuration.

LED Indicators:

  1. Power: Indicates the charger is powered on.
  2. Charging: Active charging in progress.
  3. Fully Charged: Indicates the battery is fully charged.
  4. Fault: Alerts for issues such as reverse polarity, short circuit, or overheating.

Protections:

Reverse Polarity Protection:

  • Prevents damage if battery terminals are connected incorrectly.

Overload Protection:

  • Limits the current to prevent overheating or component damage.

Short Circuit Protection:

  • Automatically shuts down to protect the system in case of a short circuit.

Overtemperature Protection:

  • Stops operation if the charger exceeds safe temperature limits.

Advantages:

  • High current output for fast charging.
  • Optimized for battery longevity and safety.
  • Suitable for demanding applications and large-capacity batteries.
  • Easy to install and operate.

Troubleshooting:

No Power or No LED Display:

  • Verify the AC input voltage.
  • Check the power cord and connections.

Battery Not Charging:

  • Ensure proper connection to the battery terminals.
  • Verify the battery is not damaged or below the minimum voltage threshold.

Fault Indicator Lit:

  • Inspect for reverse polarity or short circuit in the battery connection.
  • Allow the charger to cool down if thermal protection is triggered.

Slow Charging:

  • Ensure the battery capacity matches the charger’s output specifications.
  • Check for any high resistance in the connections.
